28764 | HELUKABEL
PVC-switching wire, H05V-U, 0.5 mm², brown, outer Ø 2.3 mm, 28764
Unit Price (€ / mtr.)
0.2213 € *
Available in 5 Days: 3,000 mtr. - if ordered today
Total Price:
22.13 € *
Price list
Quantity
Price per unit*
100 mtr.
0.2213 €
500 mtr.
0.2035 €
1000 mtr.
0.1916 €
5000 mtr.
0.1737 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC single core, 28764, HELUKABEL
The 28764 is a PVC single core for installation in electrical conduits, on and under plaster, but only for signal and control circuits. Suitable for protected and fixed installation in appliances and luminaires. The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, bright | |
| Conductor category | CL.1 = stranded | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| Colour | brown | |
| Test voltage | 2 kV | |
| Temperature range (active) | 5 °C to 70 °C | |
| Rated voltage U0 | 300 V | |
| Cable cross-section | 0.5 mm² | |
| Core insulation material | PVC | |
| Product type | switching wire | |
| Halogen free | No | |
| Rated voltage | 500 V | |
| Outer diameter | 2.3 mm | |
| Bending radius unmoved | 9.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
