26421 | HELUKABEL

PVC-switching strand, LiYv, 0.25 mm², AWG 24, 14 x 0.15 mm, black, outer Ø 1.3 mm, 26421

Order No.: 93F5471
EAN: 4060892174353
MPN:
26421
Series: LiYv
26421 HELUKABEL Insulated stranded wires
Image may differ
Unit Price (€ / mtr.)
0.3094 € *
Available: 200 mtr.
Available in 5 Days: 3,000 mtr. - if ordered today
Total Price:
30.94 € *
Price list
Quantity
Price per unit*
100 mtr.
0.3094 €
500 mtr.
0.2856 €
1000 mtr.
0.2380 €
*incl. VAT plus shipping costs
Subject to prior sale

Stranded wire, 26421, HELUKABEL

The 26421 PVC insulated, flexible hook-up wire is suitable for the wiring of low-voltage systems, telecommunication devices and electronic modules within devices, racks and switchboards. It is not permitted for heavy current installations outside of appliances.

Features

  • Copper wire tinned, 0.5-1.5 mm²: finely stranded acc. To DIN VDE 0295 Class 5 / IEC 60228 Class 5
  • Core insulation: PVC acc. to DIN VDE 0812
Technical specifications
Filter Property Value
Halogen free No
Test voltage 2.5 kV
Colour black
Outer diameter 1.3 mm
Core insulation material PVC
Temperature range (active) -5 to 70 °C
Bending radius unmoved 5.2 mm
Cable structure 14 x 0.15 mm
Cable material copper, tin-plated
AWG cross-section AWG 24
Material PVC
Rated voltage 900 V
Standard number VDE
Conductor category CL.5 = fine stranded
Temperature range (unmoved) -30 to 70 °C
Cable cross-section 0.25 mm²
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
