11019071 | HELUKABEL
PVC-switching strand, 05V-K, 1.0 mm², gray/black, outer Ø 2.8 mm, 11019071
Unit Price (€ / mtr.)
0.6545 € *
Standard delivery time from the manufacturer is: 6 Weeks
Switching strand, 11019071, HELUKABEL
This PVC single core cable is determined for the installation to the inside of apparatus as well as for the protective laying to the lightings, in dry rooms, in production facilities, switch and distributor boards, in tubes, under and surface mounting of plasters.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| Outer diameter | 2.8 mm | |
| Test voltage | 2 kV | |
| Cable material | copper, bright | |
| Conductor category | CL.5 = fine stranded | |
| Halogen free | No | |
| Temperature range (active) | -5 °C to 70 °C | |
| Colour | gray/black | |
| Rated voltage | 300 V | |
| Rated voltage U0 | 500 V | |
| Cable cross-section | 1.0 mm² | |
| Temperature range (unmoved) | -30 °C to 80 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
