83399 | HELUKABEL
PVC data cable, 4-wire, 0.82 mm², AWG 18, black, 83399
Unit Price (€ / mtr.)
2.4752 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 83399, HELUKABEL
UL-/CSA-approved, flexible data cable for use as a signal and measuring cable in machine tools, assembly lines, conveyor belts, plant construction, air conditioning devices, metallurgical plants, steel mills.
Features
- Resistant to: oil, solvents, acids, alkalis
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Outer diameter | 6.4 mm | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Shielding | unshielded | |
| Halogen free | No | |
| Number of cores | 4 | |
| Material | PVC | |
| Version | data cable | |
| Drag chain suitable | No | |
| Colour | black | |
| Core insulation material | PVC | |
| Cable material | copper, tin-plated | |
| Temperature range (active) | -10 °C to 80 °C | |
| Cable cross-section | 0.82 mm² | |
| AWG cross-section | AWG 18 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
