62752 | HELUKABEL
PVC data cable, 15-wire, 0.382 mm², AWG 22, gray, 62752
Unit Price (€ / mtr.)
25.4898 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Data cable, 62752, HELUKABEL
The 62752 is a screened, multi-core PVC data and control cable. Cross-sections with PLTC-ER and ITC-ER approval suitable for open, unprotected installation in cable trays to the machine; their outstanding oil resistance (OIL RES I & II) makes them ideally suited as connecting and joining cables and also for control, signal and measuring systems in industrial plants. The flexible cable structure facilitates installation inside and outside of machines and switch cabinets. The double-screening with aluminium foil (100% coverage) and copper braid (approx. 85% coverage) guarantee superior EMC protection. Applications: tool machines, control panels, measuring devices, production automation, cable ducts, renewable energies.
Features
- Highly flexible
- Easy to install
- Oil resistant to OIL RES I & II
Technical specifications
| Core insulation material | PVC | |
| Colour | gray | |
| Number of cores | 15 | |
| Outer diameter | 11.9 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 22 | |
| Halogen free | No | |
| Cable cross-section | 0.382 mm² | |
| Version | data cable | |
| Material | PVC | |
| Cable material | copper, tin-plated | |
| Shielding | shielded | |
| Temperature range (unmoved) | -25 °C to 105 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
