62666 | HELUKABEL
PVC data cable, 10-wire, 0.382 mm², AWG 22, gray, 62666
Unit Price (€ / mtr.)
11.0432 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 62666, HELUKABEL
The 62666 is a multi-core PVC data and control cable. Cross-sections with PLTC-ER and ITC-ER approval suitable for open, unprotected installation in cable trays to the machine; their outstanding oil resistance (OIL RES I & II) makes them ideally suited as connecting and joining cables and also for control, signal and measuring systems in industrial plants. The flexible cable structure facilitates installation inside and outside of machines and switch cabinets. Applications: tool machines, control panels, control and instrumentation technology, production automation, cable ducts, renewable energies.
Features
- Highly flexible
- Easy to install
- Oil resistant to OIL RES I & II
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Colour | gray | |
| Cable cross-section | 0.382 mm² | |
| Outer diameter | 10.1 mm | |
| Version | data cable | |
| Material | PVC | |
| AWG cross-section | AWG 22 | |
| Number of cores | 10 | |
| Temperature range (unmoved) | -25 °C to 105 °C | |
| Shielding | unshielded | |
| Core insulation material | PVC | |
| Drag chain suitable | No | |
| Cable material | copper, tin-plated |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
