59814 | HELUKABEL
PVC data cable, 4-wire, 0.616 mm², AWG 20, gray, 59814
Unit Price (€ / mtr.)
16.4101 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 59814, HELUKABEL
The 59814 is a screened, twisted pair data and control cable. Cross-sections with PLTC-ER and ITC-ER approval suitable for open, unprotected installation in cable trays to the machine; their outstanding oil resistance (OIL RES I & II) makes them ideally suited as connecting and joining cables and also for control, signal and measuring systems in industrial plants. The flexible cable structure facilitates installation inside and outside of machines and switch cabinets. The double-screening with aluminium foil (100% coverage) and copper braid (approx. 85% coverage) guarantee superior EMC protection. Applications: tool machines, control panels, measuring devices, production automation, cable ducts, renewable energies.
Features
- Highly flexible
- Easy to install
- Oil resistant to OIL RES I & II
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Colour | gray | |
| Cable cross-section | 0.616 mm² | |
| Outer diameter | 10 mm | |
| Version | data cable | |
| Material | PVC | |
| AWG cross-section | AWG 20 | |
| Number of cores | 4 | |
| Temperature range (unmoved) | -25 °C to 105 °C | |
| Shielding | shielded | |
| Core insulation material | PVC | |
| Drag chain suitable | No | |
| Cable material | copper, tin-plated |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
