52476 | HELUKABEL

Network cable, 6-wire, 0.75 mm², AWG 19, gray, 52476

Order No.: 93F6497
EAN: 4060892099991
MPN:
52476
52476 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
3.2249 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
322.49 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
3.2249 €

Network cable, 52476, HELUKABEL

The 52476 network cable is used in telecommunication devices and information processing systems in public buildings, laboratories and department stores where the release of halogens must be avoided in the event of fire. It is also used as connection cable for signal, measurement and control technology, call systems and intercoms, clock systems, electronic weighing equipment and office machines. The cable can be laid on plaster and in dry, damp and wet rooms. The halogen-free thermoplastic sheath does not emit corrosive or toxic gases.

Features

  • Halogen-free
  • Flame-retardant acc. to DIN VDE 0482-332-1-2 / DIN EN 60332- 1-2 / IEC 60332-1-2 (outer sheath)
  • PE-insulated cores ensure substantially lower capacity values than PVC-insulated cores
  • Corrosiveness of combustion gases acc. to DIN VDE 0482-754-2 / DIN EN 60754-2 / IEC 60754-2
Technical specifications
Filter Property Value
Core insulation material PE
Temperature range (unmoved) -40 °C to 70 °C
Temperature range (active) +5 °C to 70 °C
Number of cores 6
Cable material copper, bright
Cable cross-section 0.75 mm²
AWG cross-section AWG 19
Outer diameter 10.3 mm
Drag chain suitable No
Halogen free Yes
Colour gray
Shielding shielded
Version network cable
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
