49825 | HELUKABEL

PUR data cable, 12-wire, 0.34 mm², AWG 22, gray, 49825

Order No.: 93F6904
EAN: 4060892139475
MPN:
49825
49825 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
10.9718 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
1,097.18 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
10.9718 €

Drag chain cable, 49825, HELUKABEL

The 49825 is a PUR drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent and fast lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. A long service life guarantees reliable function and high efficiency. The high screening density ensures interference-free transmission of signals or pulses.

Technical specifications
Core insulation material PP
Colour gray
Number of cores 12
Outer diameter 8.3 mm
Drag chain suitable Yes
AWG cross-section AWG 22
Halogen free Yes
Cable cross-section 0.34 mm²
Version data cable
Material PUR
Cable material copper, bright
Shielding shielded
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -30 °C to 80 °C
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
