49822 | HELUKABEL
PUR data cable, 5-wire, 0.34 mm², AWG 22, gray, 49822
Unit Price (€ / mtr.)
5.5692 € *
Standard delivery time from the manufacturer is: 6 Weeks
Drag chain cable, 49822, HELUKABEL
The 49822 is a PUR drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent and fast lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. A long service life guarantees reliable function and high efficiency. The high screening density ensures interference-free transmission of signals or pulses.
Technical specifications
| Core insulation material | PP | |
| Colour | gray | |
| Number of cores | 5 | |
| Outer diameter | 6.1 mm | |
| Drag chain suitable | Yes | |
| AWG cross-section | AWG 22 | |
| Halogen free | Yes | |
| Cable cross-section | 0.34 mm² | |
| Version | data cable | |
| Material | PUR | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -30 °C to 80 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
