49799 | HELUKABEL
PUR data cable, 4-wire, 0.14 mm², AWG 26, gray, 49799
Unit Price (€ / mtr.)
3.9865 € *
Standard delivery time from the manufacturer is: 6 Weeks
Drag chain cable, 49799, HELUKABEL
The 49799 is a PUR drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent and fast lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. A long service life guarantees reliable function and high efficiency. The high screening density ensures interference-free transmission of signals or pulses.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Drag chain suitable | Yes | |
| Halogen free | Yes | |
| Cable material | copper, bright | |
| Version | data cable | |
| Cable cross-section | 0.14 mm² | |
| Shielding | shielded | |
| Colour | gray | |
| Number of cores | 4 | |
| Material | PUR | |
| Core insulation material | PP | |
| Outer diameter | 4.8 mm | |
| AWG cross-section | AWG 26 | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -30 °C to 80 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
