43524 | HELUKABEL
PVC data cable, 8-wire, 0.5 mm², AWG 20, gray, 43524
Unit Price (€ / mtr.)
4.4149 € *
Available in 5 Days: 1,000 mtr. - if ordered today
Data cable, 43524, HELUKABEL
The 43524 is a data cable with overall pair screening and low capacities for installed terminals in medical and data technology. Application is also suitable in tool and machine construction, rolling mills and smelters, as well as traffic and process technology. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and all-round large contact area of the copper braiding.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Outer diameter | 11.1 mm | |
| Version | data cable | |
| Core insulation material | PE | |
| Halogen free | No | |
| Cable cross-section | 0.5 mm² | |
| Cable material | copper, bright | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Shielding | shielded | |
| Drag chain suitable | No | |
| Colour | gray | |
| Material | PVC | |
| Number of cores | 8 | |
| AWG cross-section | AWG 20 | |
| Temperature range (active) | -5 °C to 80 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
