21540 | HELUKABEL
PVC computer cable, 16-wire, 0.5 mm², AWG 20, blue, 21540
Unit Price (€ / mtr.)
6.8187 € *
Standard delivery time from the manufacturer is: 6 Weeks
Computer cable, 21540, HELUKABEL
The 21540 is a computer cable used in data processing and process control. The individual screening of the pairs ensures good crosstalk attenuation values. When permanently installed, suitable for use in dry and damp rooms, outdoors and underground.
Technical specifications
| Core insulation material | PE | |
| Colour | blue | |
| Number of cores | 16 | |
| Outer diameter | 14.8 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 20 | |
| Halogen free | No | |
| Cable cross-section | 0.5 mm² | |
| Version | computer cable | |
| Material | PVC | |
| Cable material | copper, bright | |
| Shielding | shielded | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -5 °C to 50 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
