21537 | HELUKABEL
PVC computer cable, 4-wire, 0.5 mm², AWG 20, blue, 21537
Unit Price (€ / mtr.)
2.5942 € *
Standard delivery time from the manufacturer is: 6 Weeks
Computer cable, 21537, HELUKABEL
The 21537 is a computer cable used in data processing and process control. The individual screening of the pairs ensures good crosstalk attenuation values. When permanently installed, suitable for use in dry and damp rooms, outdoors and underground.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | computer cable | |
| Number of cores | 4 | |
| Shielding | shielded | |
| Core insulation material | PE | |
| Cable cross-section | 0.5 mm² | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -5 °C to 50 °C | |
| Drag chain suitable | No | |
| Outer diameter | 10.5 mm | |
| Colour | blue | |
| Halogen free | No | |
| AWG cross-section | AWG 20 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
