21355 | HELUKABEL
PVC data cable, 4-wire, 0.5 mm², AWG 20, gray, 21355
Unit Price (€ / mtr.)
3.1416 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 21355, HELUKABEL
The pair screened data transmission cable is used as a control and signal cable in electronics and in measurement and control technology. It provides interference-free transmission of data signals from peripheral equipment to information storage. Excellent connection cable for sound mixers, studio equipment and measurement and control technology. Reliable in process control, machining centres and safety engineering systems. This cable with copper screening is ideally suited for interefence-free data and signal transmission for measurement and control technology.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| Number of cores | 4 | |
| Version | data cable | |
| AWG cross-section | AWG 20 | |
| Temperature range (active) | -5 °C to 70 °C | |
| Halogen free | No | |
| Cable cross-section | 0.5 mm² | |
| Material | PVC | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Cable material | copper, bright | |
| Colour | gray | |
| Outer diameter | 8.3 mm | |
| Drag chain suitable | No | |
| Shielding | shielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
