20149 | HELUKABEL
PVC computer cable, 2-wire, 0.75 mm², AWG 19, black, 20149
Unit Price (€ / mtr.)
1.4518 € *
Available in 5 Days: 1,000 mtr. - if ordered today
Computer cable, 20149, HELUKABEL
This instrumentation cable is used in data processing and process control. Low level of line attenuations and low mutual capacitances enable long transmission distances and fast pulse acceleration. Instrumentation cable is suitable for fixed installations in damp locations, in open spaces and for underground laying.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 19 | |
| Colour | black | |
| Core insulation material | PE | |
| Temperature range (active) | -5 °C to 50 °C | |
| Drag chain suitable | No | |
| Halogen free | No | |
| Cable cross-section | 0.75 mm² | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Number of cores | 2 | |
| Outer diameter | 7.7 mm | |
| Material | PVC | |
| Version | computer cable | |
| Cable material | copper, bright | |
| Shielding | shielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
