20144 | HELUKABEL

PVC data cable, 32-wire, 0.5 mm², AWG 20, gray, 20144

Order No.: 93F6833
EAN: 4060892100208
MPN:
20144
Series: RD-Y(St)Y
20144 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
9.401 € *
Available: 100 mtr.
Total Price:
940.10 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
9.401 €

Data cable, 20144, HELUKABEL

This RD data transmission cable is used in measurement and control technology, as well as in control stations of industrial plants. The cable is used for the transmission of analogue and digital signals up to a frequency of approximately 10 kHz. Also is suitable for fixed installations inside buildings.

Technical specifications
Filter Property Value
Core insulation material PVC
Number of cores 32
Version data cable
AWG cross-section AWG 20
Temperature range (active) -5 °C to 50 °C
Halogen free No
Cable cross-section 0.5 mm²
Material PVC
Temperature range (unmoved) -30 °C to 70 °C
Cable material copper, bright
Colour gray
Outer diameter 13.5 mm
Drag chain suitable No
Shielding shielded
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
