20142 | HELUKABEL
PVC data cable, 16-wire, 0.5 mm², AWG 20, gray, 20142
Unit Price (€ / mtr.)
5.3193 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 20142, HELUKABEL
This RD data transmission cable is used in measurement and control technology, as well as in control stations of industrial plants. The cable is used for the transmission of analogue and digital signals up to a frequency of approximately 10 kHz. Also is suitable for fixed installations inside buildings.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Drag chain suitable | No | |
| AWG cross-section | AWG 20 | |
| Colour | gray | |
| Number of cores | 16 | |
| Outer diameter | 11.3 mm | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Shielding | shielded | |
| Temperature range (active) | -5 °C to 50 °C | |
| Cable material | copper, bright | |
| Halogen free | No | |
| Core insulation material | PVC | |
| Cable cross-section | 0.5 mm² | |
| Material | PVC | |
| Version | data cable |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
