20140 | HELUKABEL
PVC data cable, 4-wire, 0.5 mm², AWG 20, gray, 20140
Unit Price (€ / mtr.)
1.6541 € *
Available in 5 Days: 300 mtr. - if ordered today
Data cable, 20140, HELUKABEL
This RD data transmission cable is used in measurement and control technology, as well as in control stations of industrial plants. The cable is used for the transmission of analogue and digital signals up to a frequency of approximately 10 kHz. Also is suitable for fixed installations inside buildings.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | gray | |
| Outer diameter | 6.2 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 20 | |
| Number of cores | 4 | |
| Core insulation material | PVC | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Halogen free | No | |
| Material | PVC | |
| Cable material | copper, bright | |
| Version | data cable | |
| Shielding | shielded | |
| Cable cross-section | 0.5 mm² | |
| Temperature range (active) | -5 °C to 50 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
