19070 | HELUKABEL
PVC data cable, 8-wire, 0.34 mm², AWG 22, gray, 19070
Unit Price (€ / mtr.)
1.3209 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 19070, HELUKABEL
The 19070 is a PVC data cable Suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use. Used as a control and signal cable in electronic engineering, measurement and control technology and wherever wiring must be executed using the smallest possible outside diameter, with consideration of electronic possibilities, e.g. computer systems, signal technology, scales etc.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 22 | |
| Colour | gray | |
| Core insulation material | PVC | |
| Temperature range (active) | -5 °C to 80 °C | |
| Drag chain suitable | No | |
| Halogen free | No | |
| Cable cross-section | 0.34 mm² | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| Number of cores | 8 | |
| Outer diameter | 7.2 mm | |
| Material | PVC | |
| Version | data cable | |
| Cable material | copper, bright | |
| Shielding | shielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
