17035 | HELUKABEL

PVC data cable, 6-wire, 1.5 mm², AWG 16, gray, 17035

Order No.: 93F6809
EAN: 4060892090455
MPN:
17035
Series: PAAR-CY-OZ
17035 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
4.4625 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
446.25 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
4.4625 €

Data cable, 17035, HELUKABEL

The 17035 is a data cable suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use. Used as a connection cable for signal, measurement and control technology, as well as in electronic engineering. Also applicable in pulse and data technology. Special areas of application include locations with high electromagnetic radiation, e.g. through adjacent lines.

Technical specifications
Filter Property Value
Material PVC
Cable material copper, bright
Version data cable
Number of cores 6
Shielding shielded
Core insulation material PVC
Cable cross-section 1.5 mm²
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -15 °C to 80 °C
Drag chain suitable No
Outer diameter 12.2 mm
Colour gray
Halogen free No
AWG cross-section AWG 16
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free Yes
