17027 | HELUKABEL

PVC data cable, 12-wire, 1.0 mm², AWG 18, gray, 17027

Order No.: 93F6813
EAN: 4060892090370
MPN:
17027
Series: PAAR-CY-OZ
17027 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
5.3312 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
533.12 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
5.3312 €

Data cable, 17027, HELUKABEL

The 17027 is a data cable suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use. Used as a connection cable for signal, measurement and control technology, as well as in electronic engineering. Also applicable in pulse and data technology. Special areas of application include locations with high electromagnetic radiation, e.g. through adjacent lines.

Technical specifications
Filter Property Value
Colour gray
Outer diameter 13.4 mm
Drag chain suitable No
AWG cross-section AWG 18
Number of cores 12
Core insulation material PVC
Temperature range (unmoved) -40 °C to 80 °C
Halogen free No
Material PVC
Cable material copper, bright
Version data cable
Shielding shielded
Cable cross-section 1.0 mm²
Temperature range (active) -15 °C to 80 °C
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
