89978 | HELUKABEL
PVC control line JZ-602-RC-CY 4 G 2.5 mm², AWG 14, shielded, black, 89978
Unit Price (€ / mtr.)
9.7104 € *
Standard delivery time from the manufacturer is: 6 Weeks
Drag chain cable, 89978, HELUKABEL
The 89978 is a PVC drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. Due to the high screening density, interference-free transmission of signals or pulses is ensured.
Features
- Resistant to UV radiation
- Largely resistant to acids, alkalis, at room temperature
- Low adhesion
- For outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PP | |
| AWG cross-section | AWG 14 | |
| Outer diameter | 10.3 mm | |
| Test voltage | 3 kV | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.6 = finest stranded | |
| Rated voltage UL/CSA | 1000 V | |
| Halogen free | No | |
| Temperature range (active) | -5 °C to 80 °C | |
| Shielding | shielded | |
| Number of cores | 4 | |
| Colour | black | |
| Material | PVC | |
| Protective conductor available | Yes | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Drag chain suitable | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
