89932 | HELUKABEL
PVC control line JZ-602-RC 3 G 2.5 mm², AWG 14, shielded, black, 89932
Unit Price (€ / mtr.)
4.4625 € *
Standard delivery time from the manufacturer is: 6 Weeks
Drag chain cable, 89932, HELUKABEL
The 89932 is a PVC drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. RC = Robotics Cable.
Features
- Resistant to UV radiation
- Largely resistant to acids, alkalis, at room temperature
- Low adhesion
- For outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, bright | |
| Core insulation material | PP | |
| Protective conductor available | Yes | |
| Temperature range (active) | -5 °C to 80 °C | |
| Version | control line | |
| Number of cores | 3 | |
| Rated voltage UL/CSA | 1000 V | |
| Conductor category | CL.6 = finest stranded | |
| Halogen free | No | |
| Drag chain suitable | Yes | |
| Shielding | shielded | |
| AWG cross-section | AWG 14 | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Outer diameter | 8.6 mm | |
| Colour | black | |
| Test voltage | 3 kV | |
| Material | PVC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
