89919 | HELUKABEL
PVC control line JZ-602-RC 3 G 1.5 mm², AWG 16, shielded, black, 89919
Unit Price (€ / mtr.)
2.6537 € *
Standard delivery time from the manufacturer is: 6 Weeks
Drag chain cable, 89919, HELUKABEL
The 89919 is a PVC drag chain cable for installation in dry, damp and wet rooms, as well as outdoors with free movement, without tensile stress and without forced motion control. Suitable for frequent lifting and bending stress in machine and tool construction, robotics, and in permanently moving machine parts. RC = Robotics Cable.
Features
- Resistant to UV radiation
- Largely resistant to acids, alkalis, at room temperature
- Low adhesion
- For outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.6 = finest stranded | |
| Number of cores | 3 | |
| Shielding | shielded | |
| Core insulation material | PP | |
| Test voltage | 3 kV | |
| Cable cross-section | 1.5 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -5 °C to 80 °C | |
| Rated voltage UL/CSA | 1000 V | |
| Drag chain suitable | Yes | |
| Protective conductor available | Yes | |
| Outer diameter | 7.3 mm | |
| Colour | black | |
| Halogen free | No | |
| AWG cross-section | AWG 16 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
