79811 | HELUKABEL

Silicone control line THERMFLEX 180 EWKF-C 5 G 1.0 mm², AWG 18, shielded, black, 79811

Order No.: 93F6980
EAN: 4060892159510
MPN:
79811
79811 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
12.0071 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
1,200.71 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
12.0071 €

Silicone cable, 79811, HELUKABEL

The 79811 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures. An interference-free transmission of signals and pulse is assured by the high screening density

Technical specifications
Core insulation material silicone
Colour black
Number of cores 5
Protective conductor available Yes
Outer diameter 12.1 mm
Drag chain suitable No
AWG cross-section AWG 18
Test voltage 2 kV
Halogen free Yes
Cable cross-section 1.0 mm²
Version control line
Material silicone
Cable material copper, tin-plated
Shielding shielded
Rated voltage U0 300 V
Temperature range (unmoved) -60 °C to 180 °C
Temperature range (active) -25 °C to 180 °C
Conductor category CL.5 = fine stranded
Rated voltage 500 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
