75004 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 7 G 1.5 mm², AWG 16, unshielded, black, 75004
Unit Price (€ / mtr.)
9.5676 € *
Available in 5 Days: 100 mtr. - if ordered today
Silicone cable, 75004, HELUKABEL
The 75004 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Outer diameter | 10.4 mm | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| Shielding | unshielded | |
| Core colour sequence | black | |
| Halogen free | Yes | |
| Number of cores | 7 | |
| Test voltage | 2 kV | |
| Material | silicone | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Protective conductor available | Yes | |
| Drag chain suitable | No | |
| Colour | black | |
| Rated voltage | 500 V | |
| Core insulation material | silicone | |
| Cable material | copper, tin-plated | |
| Temperature range (active) | -25 °C to 180 °C | |
| Cable cross-section | 1.5 mm² | |
| AWG cross-section | AWG 16 | |
| Rated voltage U0 | 300 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
