75003 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 5 G 1.5 mm², AWG 16, unshielded, black, 75003
Unit Price (€ / mtr.)
8.0325 € *
Available in 5 Days: 1,100 mtr. - if ordered today
Silicone cable, 75003, HELUKABEL
The 75003 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, tin-plated | |
| Core insulation material | silicone | |
| Protective conductor available | Yes | |
| Temperature range (active) | -25 °C to 180 °C | |
| Version | control line | |
| Number of cores | 5 | |
| Rated voltage U0 | 300 V | |
| Conductor category | CL.5 = fine stranded | |
| Halogen free | Yes | |
| Drag chain suitable | No | |
| Shielding | unshielded | |
| AWG cross-section | AWG 16 | |
| Cable cross-section | 1.5 mm² | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| Outer diameter | 9.6 mm | |
| Colour | black | |
| Test voltage | 2 kV | |
| Material | silicone | |
| Rated voltage | 500 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
