74999 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 5 G 1.0 mm², AWG 18, unshielded, black, 74999
Unit Price (€ / mtr.)
5.7834 € *
Standard delivery time from the manufacturer is: 6 Weeks
Silicone cable, 74999, HELUKABEL
The 74999 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 5 | |
| Drag chain suitable | No | |
| Colour | black | |
| Material | silicone | |
| Cable cross-section | 1.0 mm² | |
| Conductor category | CL.5 = fine stranded | |
| Test voltage | 2 kV | |
| Cable material | copper, tin-plated | |
| Core insulation material | silicone | |
| Rated voltage | 500 V | |
| Temperature range (active) | -25 °C to 180 °C | |
| AWG cross-section | AWG 18 | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| Outer diameter | 8.8 mm | |
| Halogen free | Yes | |
| Product type | control line | |
| Shielding | unshielded |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
