74994 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 4 G 0.75 mm², AWG 19, unshielded, black, 74994
Unit Price (€ / mtr.)
4.3197 € *
Standard delivery time from the manufacturer is: 6 Weeks
Silicone cable, 74994, HELUKABEL
The 74994 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Core insulation material | silicone | |
| Colour | black | |
| Number of cores | 4 | |
| Protective conductor available | Yes | |
| Outer diameter | 7.6 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 19 | |
| Test voltage | 2 kV | |
| Halogen free | Yes | |
| Cable cross-section | 0.75 mm² | |
| Version | control line | |
| Material | silicone | |
| Cable material | copper, tin-plated | |
| Shielding | unshielded | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| Temperature range (active) | -25 °C to 180 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
