74993 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 3 G 0.75 mm², AWG 19, unshielded, black, 74993
Unit Price (€ / mtr.)
3.4272 € *
Standard delivery time from the manufacturer is: 6 Weeks
Silicone cable, 74993, HELUKABEL
The 74993 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Number of cores | 3 | |
| Cable cross-section | 0.75 mm² | |
| Halogen free | Yes | |
| Core insulation material | silicone | |
| AWG cross-section | AWG 19 | |
| Rated voltage U0 | 300 V | |
| Test voltage | 2 kV | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V | |
| Protective conductor available | Yes | |
| Colour | black | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| Cable material | copper, tin-plated | |
| Drag chain suitable | No | |
| Material | silicone | |
| Temperature range (active) | -25 °C to 180 °C | |
| Shielding | unshielded | |
| Outer diameter | 6.8 mm | |
| Version | control line |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
