74992 | HELUKABEL
Silicone control line THERMFLEX 180 EWKF 2 x 0.75 mm², AWG 19, unshielded, black, 74992
Unit Price (€ / mtr.)
2.9869 € *
Standard delivery time from the manufacturer is: 6 Weeks
Silicone cable, 74992, HELUKABEL
The 74992 is a halogen-free silicone cable for applications that require an increased mechanical strength as well as a higher temperature resistance. For use in dry, damp and wet rooms as well as outdoors. Also suitable for use in air conditioning and heating systems, in saunas and solariums, in foundries, in steel, cement and ceramic plants as well as in furnaces and lighting fixtures.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, tin-plated | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -60 °C to 180 °C | |
| AWG cross-section | AWG 19 | |
| Number of cores | 2 | |
| Colour | black | |
| Protective conductor available | No | |
| Test voltage | 2 kV | |
| Temperature range (active) | -25 °C to 180 °C | |
| Rated voltage U0 | 300 V | |
| Cable cross-section | 0.75 mm² | |
| Core insulation material | silicone | |
| Drag chain suitable | No | |
| Product type | control line | |
| Shielding | unshielded | |
| Material | silicone | |
| Halogen free | Yes | |
| Rated voltage | 500 V | |
| Outer diameter | 6.4 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
