63133 | HELUKABEL
PVC control line TRAYCONTROL 500 3 G 2.08 mm², AWG 14, unshielded, gray, 63133
Unit Price (€ / mtr.)
13.0424 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Control cable, 63133, HELUKABEL
The 63133 is a flexible, oil-resistant control cable. The special combination of TC-ER, PLTC-ER and ITC-ER allows this cableto be used as a connecting cable for industrial plant and machinery in accordance with NFPA 79. Approved for open, unprotected installation in cable trays to the machine. Its outstanding oil resistance (OIL RES I & II) guarantees a long service life for industrial applications in dry, damp and wet environments. Recommended applications: production lines, bottling plants, machine construction, switch cabinets, conveyor systems, packaging machines, automotive industry.
Features
- Highly flexible
- Easy to install
Technical specifications
| Core insulation material | PVC | |
| Colour | gray | |
| Number of cores | 3 | |
| Protective conductor available | Yes | |
| Outer diameter | 9.2 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 14 | |
| Test voltage | 3 kV | |
| Halogen free | No | |
| Cable cross-section | 2.08 mm² | |
| Version | control line | |
| Material | PVC | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Temperature range (unmoved) | -40 °C to 90 °C | |
| Temperature range (active) | -5 °C to 90 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
