60290 | HELUKABEL
PE drag chains conductor line KOMPOSPEED 600 1 x 16 mm², unshielded, black, 60290
Unit Price (€ / mtr.)
9.1035 € *
Standard delivery time from the manufacturer is: 6 Weeks
Trailing cable, 60290, HELUKABEL
The 60290 special single core is used for permanent flexible applications in machineries, machine tools, composting appliances and sewage-treatment plants, animal stalls and greenhouses and used for permanent flexible application for movable automated machinery parts and multi-shift operation as well as in open air. This cable is installed for flexible use with free movements without tensile stress or forced movements and suitable for application in drag chains.
Features
- Very good oil resistant
- Halogen free
- Abrasion resistant
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Test voltage | 3 kV | |
| Core insulation material | TPE | |
| Rated voltage U0 | 600 V | |
| Temperature range (unmoved) | -40 °C to 100 °C | |
| Temperature range (active) | -30 °C to 90 °C | |
| Material | PE | |
| Number of cores | 1 | |
| Cable material | copper, tin-plated | |
| Conductor category | CL.6 = finest stranded | |
| Cable cross-section | 16 mm² | |
| Outer diameter | 9.5 mm | |
| Drag chain suitable | Yes | |
| Halogen free | Yes | |
| Rated voltage | 1 kV | |
| Colour | black | |
| Shielding | unshielded | |
| Version | drag chains conductor line |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
