PE control line HELUTHERM 145 MULTI 3 G 2.5 mm², AWG 14, shielded, black, 53473
Unit Price (€ / mtr.)
8.6751 € *
Available in 5 Days: 700 mtr. - if ordered today
Control cable, 53473, HELUKABEL
The 53473 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Protective conductor available | Yes | |
| Temperature range (unmoved) | -55 °C to 145 °C | |
| Conductor category | CL.5 = fine stranded | |
| Version | control line | |
| Halogen free | Yes | |
| Test voltage | 3 kV | |
| Material | PE | |
| Cable material | copper, tin-plated | |
| Core insulation material | PO | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 14 | |
| Colour | black | |
| Temperature range (active) | -35 °C to 120 °C | |
| Rated voltage U0 | 450 V | |
| Shielding | shielded | |
| Rated voltage | 750 V | |
| Cable cross-section | 2.5 mm² | |
| Outer diameter | 9.9 mm | |
| Number of cores | 3 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
