53434 | HELUKABEL
PE control line HELUTHERM 145 MULTI 4 G 1.0 mm², AWG 18, shielded, black, 53434
Unit Price (€ / mtr.)
5.8072 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 53434, HELUKABEL
The 53434 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | Yes | |
| Colour | black | |
| Temperature range (unmoved) | -55 °C to 145 °C | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Cable material | copper, tin-plated | |
| Rated voltage | 500 V | |
| Material | PE | |
| Core insulation material | PO | |
| Cable cross-section | 1.0 mm² | |
| Drag chain suitable | No | |
| Temperature range (active) | -35 °C to 120 °C | |
| Version | control line | |
| Shielding | shielded | |
| Test voltage | 3 kV | |
| Number of cores | 4 | |
| Conductor category | CL.5 = fine stranded | |
| Outer diameter | 7.7 mm | |
| AWG cross-section | AWG 18 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
