53433 | HELUKABEL
PE control line HELUTHERM 145 MULTI 3 G 1.0 mm², AWG 18, shielded, black, 53433
Unit Price (€ / mtr.)
4.1174 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 53433, HELUKABEL
The 53433 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 3 | |
| Cable cross-section | 1.0 mm² | |
| Halogen free | Yes | |
| Core insulation material | PO | |
| AWG cross-section | AWG 18 | |
| Rated voltage U0 | 300 V | |
| Test voltage | 3 kV | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V | |
| Protective conductor available | Yes | |
| Colour | black | |
| Temperature range (unmoved) | -55 °C to 145 °C | |
| Cable material | copper, tin-plated | |
| Drag chain suitable | No | |
| Material | PE | |
| Temperature range (active) | -35 °C to 120 °C | |
| Shielding | shielded | |
| Outer diameter | 7 mm | |
| Version | control line |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
