53414 | HELUKABEL

PE control line HELUTHERM 145 MULTI 4 G 0.75 mm², AWG 19, shielded, black, 53414

Order No.: 93F6665
EAN: 4060892152771
MPN:
53414
53414 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
4.7481 € *
Available: 0 mtr.
Available in 5 Days: 3,000 mtr.
Leadtime: 6 Weeks **
Total Price:
474.81 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
4.7481 €

Control cable, 53414, HELUKABEL

The 53414 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.

Technical specifications
Core insulation material PO
Colour black
Number of cores 4
Protective conductor available Yes
Outer diameter 7 mm
Drag chain suitable No
AWG cross-section AWG 19
Test voltage 3 kV
Halogen free Yes
Cable cross-section 0.75 mm²
Version control line
Material PE
Cable material copper, tin-plated
Shielding shielded
Rated voltage U0 300 V
Temperature range (unmoved) -55 °C to 145 °C
Temperature range (active) -35 °C to 120 °C
Conductor category CL.5 = fine stranded
Rated voltage 500 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
