53400 | HELUKABEL
PE control line HELUTHERM 145 MULTI 12 G 0.5 mm², AWG 20, shielded, black, 53400
Unit Price (€ / mtr.)
11.2812 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 53400, HELUKABEL
The 53400 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Core insulation material | PO | |
| Colour | black | |
| Number of cores | 12 | |
| Protective conductor available | Yes | |
| Outer diameter | 10 mm | |
| Drag chain suitable | No | |
| AWG cross-section | AWG 20 | |
| Test voltage | 3 kV | |
| Halogen free | Yes | |
| Cable cross-section | 0.5 mm² | |
| Version | control line | |
| Material | PE | |
| Cable material | copper, tin-plated | |
| Shielding | shielded | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -55 °C to 145 °C | |
| Temperature range (active) | -35 °C to 120 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
