53392 | HELUKABEL
PE control line HELUTHERM 145 MULTI 2 x 0.5 mm², AWG 20, shielded, black, 53392
Unit Price (€ / mtr.)
3.0107 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 53392, HELUKABEL
The 53392 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage U0 | 300 V | |
| Temperature range (active) | -35 °C to 120 °C | |
| Test voltage | 3 kV | |
| Rated voltage | 500 V | |
| Cable material | copper, tin-plated | |
| Drag chain suitable | No | |
| Version | control line | |
| Material | PE | |
| Protective conductor available | No | |
| Colour | black | |
| Outer diameter | 5.3 mm | |
| Cable cross-section | 0.5 mm² | |
| AWG cross-section | AWG 20 | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -55 °C to 145 °C | |
| Halogen free | Yes | |
| Shielding | shielded | |
| Number of cores | 2 | |
| Core insulation material | PO |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
