49846 | HELUKABEL
PUR control line SUPER-PAAR-TRONIC 340-C-PUR 10 G 0.34 mm², AWG 22, shielded, gray, 49846
Unit Price (€ / mtr.)
13.8516 € *
Standard delivery time from the manufacturer is: 6 Weeks
Halogen-free control cable, 49846, HELUKABEL
Stranded in pairs, these fully-screened special drag chain cables can also be used where external, high-frequency interference influences pulse transfer. They are used for permanently flexible stresses in machine and tool building, in robot technology, on constantly moving machine components and for extended use in multi-shift operations. Developed to state-of-the-art technology, these highly flexible data cable, with a cut resistant and low-adhesion PUR outer sheath guaranteeing optimal service life and extremely good cost efficiency.
FEATURES
- Halogen-free
- Good chemical resistance
- Oil-resistant
- Weather, ozone and UV-resistant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PP
- Color: gray
- Conductor category: Cl.6 = finest-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Standard number | UL, CSA | |
| Cable material | copper, bright | |
| Test voltage | 1.5 kV | |
| Conductor category | CL.6 = finest stranded | |
| Core insulation material | PUR | |
| Material | PUR | |
| Version | control line | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -30 °C to 80 °C | |
| Rated voltage U0 | 300 V | |
| Halogen free | Yes | |
| Protective conductor available | Yes | |
| Outer diameter | 12.1 mm | |
| AWG cross-section | AWG 22 | |
| Drag chain suitable | Yes | |
| Colour | gray | |
| Number of cores | 10 | |
| Rated voltage | 300 V | |
| Shielding | shielded | |
| Cable cross-section | 0.34 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
