49683 | HELUKABEL
PUR control line SUPERTRONIC-C-PURö 18 x 0.34 mm², AWG 22, shielded, gray, 49683
Unit Price (€ / mtr.)
10.0317 € *
Standard delivery time from the manufacturer is: 6 Weeks
Halogen-free control cable, 49683, HELUKABEL
Used for installation in dry, moist and wet environments as well as for outdoors, for free movement without forced motion and for flexible routing without forced motion, for proven use as drag-chain cables. Suitable as a highly flexible control cable for fast hoisting and bending stresses in machinery and tooling construction, in robotics engineering and for continuously moving machinery parts. The long working life of this cable makes it both efficient and economic. The copper braided screening offers effective protection from both internal and external interference.
FEATURES
- Tear-resistant
- UV-resisant
- Cadmium-free
- Abrasion-resistance
Technical Data
- Cable material: Copper, bright
- Core insulation material: PP
- Color: gray
- Conductor category: Cl.6 = finest-stranded
Technical specifications
| Conductor category | CL.5 = fine stranded | |
| Shielding | shielded | |
| AWG cross-section | AWG 22 | |
| Colour | gray | |
| Test voltage | 1.2 kV | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| Core insulation material | PUR | |
| Drag chain suitable | Yes | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -30 °C to 70 °C | |
| Number of cores | 18 | |
| Cable cross-section | 0.34 mm² | |
| Version | control line | |
| Outer diameter | 10.9 mm | |
| Protective conductor available | No | |
| Material | PUR | |
| Cable material | copper, bright |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
