Rubber connection cable H07ZZ-F 5 G 1.5 mm², AWG 16, unshielded, black, 37237
Unit Price (€ / mtr.)
4.4030 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 37237, HELUKABEL
The 37237 is a connection cable for use in dry, damp and wet rooms in commercial and agricultural workshops for connecting equipment where cable is subject to heavy mechanical loads. When laid in pipes or similar closed systems, the use of the cable is permitted up to and including 1000 V AC or 750 V DC against earth.
Features
- Resistant to ozone
- Halogen-free
- Suitable for outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 16 | |
| Core insulation material | rubber | |
| Temperature range (active) | -5 °C to 80 °C | |
| Test voltage | 2.5 kV | |
| Colour | black | |
| Halogen free | Yes | |
| Number of cores | 5 | |
| Shielding | unshielded | |
| Outer diameter | 14.4 mm | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Material | rubber | |
| Rated voltage U0 | 450 V | |
| Protective conductor available | Yes | |
| Rated voltage | 750 V | |
| Drag chain suitable | No | |
| Product type | connection cable | |
| Cable material | copper, bright | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
