37196 | HELUKABEL
Rubber connection cable H07ZZ-F 2 x 2.5 mm², AWG 14, unshielded, black, 37196
Unit Price (€ / mtr.)
4.4863 € *
Standard delivery time from the manufacturer is: 6 Weeks
Connection cable, 37196, HELUKABEL
The 37196 is a connection cable for use in dry, damp and wet rooms in commercial and agricultural workshops for connecting equipment where cable is subject to heavy mechanical loads. When laid in pipes or similar closed systems, the use of the cable is permitted up to and including 1000 V AC or 750 V DC against earth.
Features
- Resistant to ozone
- Halogen-free
- Suitable for outdoor use
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | rubber | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Number of cores | 2 | |
| Shielding | unshielded | |
| Core insulation material | rubber | |
| Test voltage | 2.5 kV | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Temperature range (active) | -5 °C to 80 °C | |
| Rated voltage U0 | 450 V | |
| Drag chain suitable | No | |
| Protective conductor available | No | |
| Outer diameter | 13.1 mm | |
| Colour | black | |
| Rated voltage | 750 V | |
| Halogen free | Yes | |
| AWG cross-section | AWG 14 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
