29469 | HELUKABEL
PVC control line H05VV-F 3 G 1.5 mm², AWG 16, unshielded, white, 29469
Unit Price (€ / mtr.)
1.4518 € *
Available in 5 Days: 1,000 mtr. - if ordered today
Total Price:
145.18 € *
Price list
Quantity
Price per unit*
100 mtr.
1.4518 €
500 mtr.
1.2971 €
*incl. VAT plus shipping costs
Subject to prior sale
Control cable, 29469, HELUKABEL
These cables are especially suited to use for the appliance with medium mechanical stress in households, kitchens and offices, also for household appliances in damp and wet areas, e. g. refrigerators, washing machines, spin-driver etc. As far as this cable is admitted to the relevant specifications of the equipment.
FEATURES
- Free from harmful substances
- Oil-resistant
- Cadmium-free
- Flame-retardant
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: white
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Shielding | unshielded | |
| Test voltage | 2 kV | |
| Colour | white | |
| Drag chain suitable | No | |
| Rated voltage U0 | 300 V | |
| Outer diameter | 8.2 mm | |
| Protective conductor available | Yes | |
| Core insulation material | PVC | |
| Temperature range (active) | -5 °C to 70 °C | |
| Number of cores | 3 | |
| Cable material | copper, bright | |
| AWG cross-section | AWG 16 | |
| Material | PVC | |
| Rated voltage | 500 V | |
| Standard number | VDE | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Cable cross-section | 1.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
