26184 | HELUKABEL
Thermoplastic control line KOMPOFLEX JZ-500 7 G 2.5 mm², AWG 14, unshielded, black, 26184
Unit Price (€ / mtr.)
8.9012 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 26184, HELUKABEL
Extremly robust universal cable. This cable is specially installed in rubbish, sewage-treatment plants, composting works, animal stalls and greenhouses. Suitable for installation for flexible use for medium mechanical, stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside.
Features
- Resistant to UV-radiation, Oxygene, Ozone, Microbes, Hydrofluoric acid, Hydrochloric acid and diluted sulfuric acid
- Low adhesion
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | thermoplastic | |
| Cable material | copper, tin-plated | |
| Version | control line | |
| Conductor category | CL.5 = fine stranded | |
| Number of cores | 7 | |
| Shielding | unshielded | |
| Core insulation material | thermoplastic | |
| Test voltage | 3 kV | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -40 °C to 100 °C | |
| Temperature range (active) | -30 °C to 90 °C | |
| Rated voltage U0 | 300 V | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| Outer diameter | 12.1 mm | |
| Colour | black | |
| Rated voltage | 500 V | |
| Halogen free | Yes | |
| AWG cross-section | AWG 14 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
