26181 | HELUKABEL
Thermoplastic control line KOMPOFLEX JZ-500 3 G 2.5 mm², AWG 14, unshielded, black, 26181
Unit Price (€ / mtr.)
3.9270 € *
Standard delivery time from the manufacturer is: 6 Weeks
Control cable, 26181, HELUKABEL
Extremly robust universal cable. This cable is specially installed in rubbish, sewage-treatment plants, composting works, animal stalls and greenhouses. Suitable for installation for flexible use for medium mechanical, stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside.
Features
- Resistant to UV-radiation, Oxygene, Ozone, Microbes, Hydrofluoric acid, Hydrochloric acid and diluted sulfuric acid
- Low adhesion
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Conductor category | CL.5 = fine stranded | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (active) | -30 °C to 90 °C | |
| Shielding | unshielded | |
| Test voltage | 3 kV | |
| Version | control line | |
| Rated voltage U0 | 300 V | |
| Rated voltage | 500 V | |
| Protective conductor available | Yes | |
| Outer diameter | 8.3 mm | |
| Number of cores | 3 | |
| AWG cross-section | AWG 14 | |
| Core insulation material | thermoplastic | |
| Colour | black | |
| Halogen free | Yes | |
| Material | thermoplastic | |
| Temperature range (unmoved) | -40 °C to 100 °C | |
| Cable material | copper, tin-plated | |
| Drag chain suitable | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
