24150 | HELUKABEL

PUR connection cable MULTISPEED 500-PUR 4 G 2.5 mm², AWG 14, unshielded, black, 24150

Order No.: 93F8246
EAN: 4060892134432
MPN:
24150
24150 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
6.9496 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
694.96 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
6.9496 €

Connecting cable, 24150, HELUKABEL

PUR drag chain cable suitable for continuous operation with long travelling distance capabilities at high or low speeds in dry, damp and wet rooms, as well as outdoors. For applications where the highest demands are placed on flexibility and abrasion resistance, e.g. in energy supply chains, industrial robots, production lines, automation systems and on permanently moving machine parts for uninterrupted operation.

Features

  • Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion
  • Highly restistant to alternate bending strength
  • Halogen-free
Technical specifications
Core insulation material PP
Colour black
Number of cores 4
Protective conductor available Yes
Outer diameter 8.8 mm
Drag chain suitable Yes
AWG cross-section AWG 14
Test voltage 3 kV
Halogen free Yes
Cable cross-section 2.5 mm²
Version connection line
Material PUR
Cable material copper, bright
Shielding unshielded
Rated voltage U0 300 V
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -30 °C to 80 °C
Rated voltage 500 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
