24033 | HELUKABEL
PVC control line HELUTHERM 120 5 G 1.5 mm², AWG 16, black, 24033
Unit Price (€ / mtr.)
4.6172 € *
Available in 5 Days: 100 mtr. - if ordered today
PVC Control cable, 24033, HELUKABEL
Therm cables are ideal for use in machines, appliances or motors which are subject to direct contact with high temperatures (e. g. varnishing machines and drying towers etc.). For application in dry, moist and wet rooms and in open air.
FEATURES
- Flame-retardant
- Good chemical resistance
- Oil-resistant
- Cadmium-free
Technical Data
- Cable material: Copper, bright
- Core insulation material: PVC
- Color: black
- Conductor category: Cl.5 = fine-stranded
Technical specifications
| Core insulation material | PVC | |
| Colour | black | |
| Number of cores | 5 | |
| Protective conductor available | Yes | |
| Outer diameter | 10 mm | |
| AWG cross-section | AWG 16 | |
| Test voltage | 2 kV | |
| Halogen free | No | |
| Cable cross-section | 1.5 mm² | |
| Version | control line | |
| Material | PVC | |
| Cable material | copper, bright | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -30 °C to 105 °C | |
| Temperature range (active) | -5 °C to 105 °C | |
| Conductor category | CL.5 = fine stranded | |
| Rated voltage | 500 V |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
