22258 | HELUKABEL

PUR control line PUR-ORANGE 2 x 1.5 mm², AWG 16, orange, 22258

Order No.: 93F2353
EAN: 4099891247102
MPN:
22258
Series: PUR-ORANGE
22258 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
2.3443 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
234.43 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
2.3443 €

Control cable, 22258, HELUKABEL

Robust connecting and control cable with an outstanding resistance to oil and abrasion. Suitable for use in tool making and machine industries, steel works, on building sites and in the oil and coal industries. The cable can also be used for portable tools. etc. To be recommended if the cable comes into contact with chemical agents.

FEATURES

  • High flexibility at low temperature
  • Oil-resistant
  • UV-resistant
  • High abrasion resistance

Technical Data

  • Cable material: Copper, bright
  • Core insulation material: PVC
  • Color: orange
  • Conductor category: Cl.5 = fine-stranded
Technical specifications
Filter Property Value
Core insulation material PVC
Colour orange
Number of cores 2
Protective conductor available No
Outer diameter 7.8 mm
Drag chain suitable No
AWG cross-section AWG 16
Test voltage 3 kV
Halogen free No
Cable cross-section 1.5 mm²
Version control line
Material PUR
Cable material copper, bright
Rated voltage U0 300 V
Temperature range (unmoved) -40 °C to 80 °C
Temperature range (active) -15 °C to 80 °C
Conductor category CL.5 = fine stranded
Rated voltage 500 V
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
